How To Mount and Unmount A Range Screen

  • Updated

Due to limited availability of 27” screens, you will receive our current 32” screen as a replacement.

Please note that only the display is larger — the mounting dimensions remain the same, so it will fit perfectly in your existing Theft Protection (TP) setup.

Once your new screen arrives, please watch the videos below or follow these steps for mounting and unmounting guidance:

  1. Gently loosen the screws from the back of the TP and the 27” screen.
  2. Lift the screen slightly upward to remove it.
  3. Remove the middle lower small shelf to fit the 32” screen
  4. Place the new 32” screen in position.
  5. Tighten the screws on the back to secure the TP and screen.

Unmounting A Screen

For instructions on how to unmount the screen, please see the video below:


Mounting A Screen

If you need to mount a range screen, please refer to the first video below:
